Allen-Bradley Compact 5000 I/O Modules

Compact 5000 I/O Modules

Our Bulletin 5069 Compact 5000™ I/O modules provide high-performance control in a compact design, and expand the performance capabilities of the Logix platform. They are the local I/O modules in a CompactLogix™ 5380Compact GuardLogix® 5380, or CompactLogix 5480 system and safety options are available. These modules are the ideal distributed I/O solution on an EtherNet/IP network for CompactLogix 5380, Compact GuardLogix® 5380, CompactLogix 5480,  ControlLogix® 5580, and GuardLogix 5580 controllers with safety module restrictions. They are great for applications with high-processing requirements.

Compact 5000 I/O |  Overview

Overview

Compact 5000 I/O Standard Modules

  • Are available in high-speed counter, digital input, digital output, analog input, analog output, AC input, AC output, isolated and non-isolated relay output, address reserve modules, and field potential distributor
  • Function as local I/O in a CompactLogix™ 5380, Compact GuardLogix 5380, or CompactLogix 5480 control system or as distributed I/O accessible via a 5069-AEN2TR or 5069-AENTR over an EtherNet/IP network for CompactLogix 5380, Compact GuardLogix 5380, CompactLogix 5480, ControlLogix 5580, and GuardLogix 5580 controllers
  • Provide field-side power to field-side devices that are connected to some Compact 5000 I/O modules

Compact 5000 I/O EtherNet/IP Communication Modules

  • Support up to 31 I/O modules
  • Provide separate system power for better isolation and built-in power input with field power to I/O modules
  • Support distributed I/O modules via an EtherNet/IP network for CompactLogix 5380, Compact GuardLogix 5380, CompactLogix 5480, ControlLogix 5580, and GuardLogix 5580 controllers
  • Support 1 Gb embedded switch technology for Linear and Device Level Ring topologies
  • Provide high-speed backplane communications for faster transfer rates
  • Provide improved status indicators to monitor and troubleshoot systems
  • Use the slim 5069-AENTR for small space requirements

Compact 5000 I/O Safety Modules

  • Provide a local safety connectivity to the Compact GuardLogix 5380
  • Provide distributed I/O to the Compact GuardLogix 5380 and GuardLogix 5580, which is accessible via a 5069-AEN2TR or 5069-AENTR over an EtherNet/IP
  • Support up to 31 I/O modules per controller or adapter
  • Provide faster safety reaction time
  • Provide enhanced diagnostics information
  • Rated up to SIL3/PLe

Product Selection

Catalog Number Description
5069-AENTR5069 Compact I/O Slim EtherNet/IP Adapter
5069-AENTRK5069 Compact I/O Slim EtherNet/IP Adapter,Conformal Coated
5069-AEN2TR5069 Compact I/O EtherNet/IP Adapter
5069-IY45069 Compact I/O 4 Channel Universal Voltage/Current/RTD/TC Analog Input Module
5069-IF85069 Compact I/O 8 Channel Voltage/Current Analog Input Module
5069-OF45069 Compact I/O 4 Channel Voltage/Current Analog Output Module
5069-OF85069 Compact I/O 8 Channel Voltage/Current Analog Output Module
5069-IB8SCompact 5000 8 Channel 24VDC Safety Input Module
5069-IB8SKCompact 5000 8 Channel 24VDC Safety Input Module – Conformally Coated
5069-IB16K5069 Compact I/O 16 Channel 24V DC Sink Input Module,Conformal Coated
5069-IA165069 Compact I/O 16 channels AC input modules, supporting both 120 & 240 VAC signals
5069-IB165069 Compact I/O 16 Channel 24V DC Sink Input Module
5069-IB16F5069 Compact I/O 16 Channel Fast 24V DC Sink Input Module
5069-IB6F-3W5069 Compact I/O 6 Channel 3 Wire Fast 24V DC Sink Input Module
5069-OA165069 Compact I/O 16 channels AC output module supporting both 120 & 240VAC output.
5069-OB85069 Compact I/O 8 channels high current 2A discrete output.
5069-OBV8SCompact 5000 8 Channel 24VDC Safety Configurable Output Module
5069-OBV8SKCompact 5000 8 Channel 24VDC Safety Configurable Output Module – Conformally Coated
5069-OB165069 Compact I/O 16 Channel 24V DC Source Output Module
5069-OB16F5069 Compact I/O 16 Channel Fast 24V DC Source Output Module
5069-OB16K5069 Compact I/O 16 Channel 24V DC Source Output Module,Conformal Coated
5069-IY4K5069 Compact I/O 4 Channel Universal Voltage/Current/RTD/TC Analog Input Module,Conformal Coated
5069-OF4K5069 Compact I/O 4 Channel Voltage/Current Analog Output Module,,Conformal Coated
5069-OW4I5069 Compact I/O 4 Channel Normally open individually isolated type Relay Output Module
5069-OW165069 Compact I/O 16 channels non isolated normally open relay output module.
5069-OX4I5069 Compact I/O 4 Channel Normally open/Normally Closed individually isolated type Relay Output Module
5069-FPD5069 Compact I/O Field Potential Distributor Module
5069-HSC2XOB45069 Compact I/O 2 Channel High Speed Counter Module with 4 Channel 24V DC Source Outputs
5069-ARM5069 Compact I/O Address Reserve Module
5069-L306ERController, CompactLogix 5380, 600 KB User Memory, 8 I/Os, 16 EtherNet/IP Devices
5069-L310ERController, CompactLogix 5380, 1 MB User Memory, 8 I/Os, 24 EtherNet/IP Devices
5069-L320ERController, CompactLogix 5380, 2 MB, 16 I/Os, 40 EtherNet/IP Devices
5069-L320ERPCompactLogix 5380 Controller, 2 MB, 16 I/Os, 8 axis, 40 nodes, Process, Conformal Coated
5069-L330ERController, CompactLogix 5380, 3 MB User Memory, 31 I/Os, 60 EtherNet/IP Devices
5069-L340ERController, CompactLogix 5380, 4 MB User Memory, 31 I/Os, 90 EtherNet/IP Devices
5069-L340ERPCompactLogix 5380 Controller, 4 MB, 31 I/Os, 20 axis, 90 nodes, Process, Conformal Coated
5069-L310ER-NSEController, CompactLogix 5380, 1 MB User Memory, 8 I/Os, 24 EtherNet/IP Devices, No Super Cap
5069-L306ERMController, CompactLogix 5380, 600 KB User Memory, 8 I/Os, 2 axis, 16 EtherNet/IP Devices
5069-L310ERMController, CompactLogix 5380, 1 MB User Memory, 8 I/Os, 4 axis, 24 EtherNet/IP Devices
5069-L310ERMKController, CompactLogix 5380, 1 MB User Memory, 8 I/Os, 4 axis, 24 EtherNet/IP Devices, Conformally Coated
5069-L320ERMController, CompactLogix 5380, 2 MB, 16 I/Os, 8 axis, 40 EtherNet/IP Devices
5069-L320ERMKCompactLogix 5380 Controller, 2 MB, 16 I/Os, 8 axis, 40 nodes, Standard, Conformal Coated
5069-L330ERMController, CompactLogix 5380, 3 MB User Memory, 31 I/Os, 16 axis, 60 EtherNet/IP Devices
5069-L330ERMKCompactLogix 5380 Controller, 3 MB, 31 I/Os, 16 axis, 60 nodes, Standard, Conformal Coated
5069-L340ERMController, CompactLogix 5380, 4 MB User Memory, 31 I/Os, 20 axis, 90 EtherNet/IP Devices
5069-L350ERMController, CompactLogix 5380, 5 MB User Memory, 31 I/Os, 24 axis, 120 EtherNet/IP Devices
5069-L350ERMKCompactLogix 5380 Controller, 5 MB, 31 I/Os, 24 axis, 120 nodes, Standard, Conformal Coated
5069-L380ERMController, CompactLogix 5380, 8 MB User Memory, 31 I/Os, 28 axis, 150 EtherNet/IP Devices
5069-L3100ERMController, CompactLogix 5380, 10 MB User Memory, 31 I/Os, 32 axis, 180 EtherNet/IP Devices
5069-L306ERS2Controller, Compact GuardLogix 5380, SafetySIL2/PLd, 0.6MB Standard & 0.3MB Safety Memory, 16 nodes, 8 I/Os
5069-L310ERS2Controller, Compact GuardLogix 5380 Safety, SIL2/PLd, 1.0MB Standard & 0.5MB Safety Memory, 24 nodes, 8 I/Os
5069-L320ERS2Controller, Compact GuardLogix 5380 Safety, SIL2/PLd, 2.0MB Standard & 1.0MB Safety Memory, 40 nodes, 16 I/Os
5069-L330ERS2Controller, Compact GuardLogix 5380 Safety, SIL2/PLd, 3.0MB Standard & 1.5MB Safety Memory, 60 nodes, 31 I/Os
5069-L340ERS2Controller, Compact GuardLogix 5380 Safety, SIL2/PLd, 4.0MB Standard & 2.0MB Safety Memory, 90 nodes, 31 I/Os
5069-L350ERS2Controller, Compact GuardLogix 5380 Safety, SIL2/PLd, 5.0MB Standard & 2.5MB Safety Memory, 120 nodes, 31 I/Os
5069-L380ERS2Controller, Compact GuardLogix 5380 Safety, SIL2/PLd, 8.0MB Standard & 4.0MB Safety Memory, 150 nodes, 31 I/Os
5069-L3100ERS2Controller, Compact GuardLogix 5380 Safety, SIL2/PLd, 10.0MB Standard & 5.0MB Safety Memory, 180 nodes, 31 I/Os
5069-L306ERMS2Controller, Compact GuardLogix 5380 Safety, SIL2/PLd, 0.6MB Standard & 0.3MB Safety Memory, 16 nodes, 8 I/Os, 2 axis
5069-L310ERMS2Controller, Compact GuardLogix 5380 Safety, SIL2/PLd, 1.0MB Standard & 0.5MB Safety Memory, 24 nodes, 8 I/Os, 4 axis
5069-L320ERMS2Controller, Compact GuardLogix 5380 Safety SIL2/PLd, 2.0MB Standard & 1.0MB Safety Memory, 40 nodes, 16 I/Os, 8 axis
5069-L330ERMS2Controller, Compact GuardLogix 5380 Safety, SIL2/PLd, 3.0MB Standard & 1.5MB Safety Memory, 60 nodes, 31 I/Os, 16 axis
5069-L340ERMS2Controller, Compact GuardLogix 5380 Safety, SIL2/PLd, 4.0MB Standard & 2.0MB Safety Memory, 90 nodes, 31 I/Os, 20 axis
5069-L350ERMS2Controller, Compact GuardLogix 5380 Safety, SIL2/PLd, 5.0MB Standard & 2.5MB Safety Memory, 120 nodes, 31 I/Os, 24 axis
5069-L380ERMS2Controller, Compact GuardLogix 5380 Safety, SIL2/PLd, 8.0MB Standard & 4.0MB Safety Memory, 150 nodes, 31 I/Os, 28 axis
5069-L3100ERMS2Controller, Compact GuardLogix 5380 Safety, SIL2/PLd, 10.0MB Standard & 5.0MB Safety Memory, 180 nodes, 31 I/Os, 32 axis
5069-L320ERS2KController, Compact GuardLogix 5380 Safety, SIL2/PLd, 2.0MB Standard & 1.0MB Safety Memory, 40 nodes, 16 I/Os, Conformal Coated
5069-L320ERMS2KController, Compact GuardLogix 5380 Safety, SIL2/PLd, 2.0MB Standard & 1.0MB Safety Memory, 40 nodes, 16 I/Os, 8 axis, Conformal Coated
5069-L330ERS2KController, Compact GuardLogix 5380 Safety, SIL2/PLd, 3.0MB Standard & 1.5MB Safety Memory, 60 nodes, 31 I/Os, Conformal Coated
5069-L330ERMS2KController, Compact GuardLogix 5380 Safety, SIL2/PLd, 3.0MB Standard & 1.5MB Safety Memory, 60 nodes, 31 I/Os, 16 axis, Conformal Coated
5069-L350ERS2KController, Compact GuardLogix 5380 Safety, SIL2/PLd, 5.0MB Standard & 2.5MB Safety Memory, 120 nodes, 31 I/Os, Conformal Coated
5069-L350ERMS2KController, Compact GuardLogix 5380 Safety, SIL2/PLd, 5.0MB Standard & 2.5MB Safety Memory, 120 nodes, 31 I/Os, 24 axis, Conformal Coated
5069-L306ERMS3Compact GuardLogix5380 Safety Controller, SIL3/PLe, 0.6MB Standard & 0.3MB Safety Memory, 16 nodes, 8 I/Os, 2 axis
5069-L310ERMS3Compact GuardLogix5380 Safety Controller, SIL3/PLe, 1.0MB Standard & 0.5MB Safety Memory, 24 nodes, 8 I/Os, 4 axis
5069-L310ERMS3KCompact GuardLogix5380 Safety Controller, SIL3/PLe, 1.0MB Standard & 0.5MB Safety Memory, 24 nodes, 8 I/Os, 4 axis – Conformally Coated
5069-L320ERMS3Compact GuardLogix5380 Safety Controller, SIL3/PLe, 2.0MB Standard & 1.0MB Safety Memory, 40 nodes, 16 I/Os, 8 axis
5069-L320ERMS3KCompact GuardLogix5380 Safety Controller, SIL3/PLe, 2.0MB Standard & 1.0MB Safety Memory, 40 nodes, 16 I/Os, 8 axis – Conformally Coated
5069-L330ERMS3Compact GuardLogix5380 Safety Controller, SIL3/PLe, 3.0MB Standard & 1.5MB Safety Memory, 60 nodes, 31 I/Os, 16 axis
5069-L330ERMS3KCompact GuardLogix5380 Safety Controller, SIL3/PLe, 3.0MB Standard & 1.5MB Safety Memory, 60 nodes, 31 I/Os, 16 axis – Conformally Coated
5069-L340ERMS3Compact GuardLogix5380 Safety Controller, SIL3/PLe, 4.0MB Standard & 2.0MB Safety Memory, 90 nodes, 31 I/Os, 20 axis
5069-L350ERMS3Compact GuardLogix5380 Safety Controller, SIL3/PLe, 5.0MB Standard & 2.5MB Safety Memory, 120 nodes, 31 I/Os, 24 axis
5069-L350ERMS3KCompact GuardLogix5380 Safety Controller, SIL3/PLe, 5.0MB Standard & 2.5MB Safety Memory, 120 nodes, 31 I/Os, 24 axis – Conformally Coated
5069-L380ERMS3Compact GuardLogix5380 Safety Controller, SIL3/PLe, 8.0MB Standard & 4.0MB Safety Memory, 150 nodes, 31 I/Os, 28 axis
5069-L3100ERMS3Compact GuardLogix5380 Safety Controller, SIL3/PLe, 10.0MB Standard & 5.0MB Safety Memory, 180 nodes, 31 I/Os, 32 axis
5069-L430ERMWController, CompactLogix, 03 MB User Memory, USB Port, 1GB Ethernet port, 60 EtherNet/IP Devices, 4 Character Alpha/Numeric Display, 31 I/Os, 16 axis, Windows 10 IoT, 64GB SSD
5069-L450ERMWController, CompactLogix, 05 MB User Memory, USB Port, 1GB Ethernet port, 120 EtherNet/IP Devices, 4 Character Alpha/Numeric Display, Windows 10 IoT, 31 I/Os, 24 axis, 64GB SSD
5069-L4100ERMWController, CompactLogix, 10 MB User Memory, USB Port,1GB Ethernet port, 180 EtherNet/IP Devices, 4 Character Alpha/Numeric Display, Windows 10 IoT, 31 I/Os, 32 axis, 64GB SSD
5069-L4200ERMWController, CompactLogix, 20 MB User Memory, USB Port, 1GB Ethernet port,250 EtherNet/IP Devices, 4 Character Alpha/Numeric Display, 31 I/Os, 150 axis, Windows 10 IoT, 64GB SSD
5069-SERIALCompact 5000 Serial Interface Module
